Camlock Couplings Design principle : the principle behind the design of camlock is simple. Pivot pins for coupler cam arms which lock into the adaptor groove are located so that when line pressure attempts to force the camlock, the bottom edge of the adaptor grooves pushes with equal pressure against the under edge of the cam arm increasing the locking action, when properly connected, line pressure will not separate a camlock with recommended pressure limit.
End connection : socket weld, hose thread, pipe thread, hose and flanged. Size : 1/2" to 6" depending on type and material. Working pressure : for 1/2" to 2" sizes - 500 p. S. I. For 3" to 4" sizes - 200 p. S. I. For 5" to 6" sizes - 100 p. S. I. Temperature : the coupler can handle fluid from - 400 to + 3500c with right selection of body material and seal. Application : Camlock finds usage in various industries like fertilizers, chemicals, petroleums, textiles, minings, brewings, inks, dyes, paper mills, processing plants etc. Materials : Camlock are manufactured from selected raw materials under strict quality control. body :
Available in solid bar stock of aluminum, mild steel, brass SS 304 & SS 316.
Available in castings of carbon steel grade WCB or I. S. 1030, gunmetal grade lg2c, aluminium bronze grade ab2c, ss 304 with C. F. 0. 08 & SS 316 with C. F. 0. 08.
Cam arms : available in casting of SS 304 with C. F. 0. 08, SS 316 with C. F. 0. 08, gunmetal grade lg2c & al
